The Residential Aluminum Fence (Hundred Series) features ⅝” pickets with 1⅛” x 1″ rails. With 16 models, a variety of satin, textured, and multi-colored finishes, and hidden picket fasteners creating a screwless system, the hard part will be selecting the style that defines you.

Model 2220 – 2-RAIL FLAT TOP

FENCE SPECIFICATIONS
Height: 54″*
Sections: 8′ Centers (Standard); Available in Per Foot Sections from 3′ to 8′
and Per Inch Sections from 36″ to 96″ (even spacing between verticals)
Standard Posts: 2 1/2″ x 2 1/2″ (.090″)
Heavy Duty Posts: 2 1/2″ x 2 1/2″ (.125″)
Gate Posts: 2 1/2″ x 2 1/2 (.090″) w/ Inserts = .215″ Wall, 4″ x 4″ (.125″), 6″ x 6″ (.185″)
Post Caps: 2 1/2″, 4″, 6″ Flat (Standard); 2 1/2″, 4″ Ball (Optional)
Rails: 1 1/2″ (.070″) w x 1 1/2″ (.100″) h
Pickets: 1″ x 1″ (.065″)
Picket Spacing: 3.75″ between pickets
Racking: Standard Section Racks 17″ in an 8′ Section

Model 2230 – 3-RAIL FLAT TOP

FENCE SPECIFICATIONS
Heights: 48″, 54″, 60″, 72″
Sections: 8′ Centers (Standard); Available in Per Foot Sections from 3′ to 8′
and Per Inch Sections from 36″ to 96″ (even spacing between verticals)
Standard Posts: 2 1/2″ x 2 1/2″ (.090″)
Heavy Duty Posts: 2 1/2″ x 2 1/2″ (.125″)
Gate Posts: 2 1/2″ x 2 1/2″ (.090″) w/ Inserts = .215″ Wall, 4″ x 4″ (.125″), 6″ x 6″ (.185″)
Post Caps: 2 1/2″, 4″, 6 Flat (Standard); 2 1/2″, 4″ Ball (Optional)
Rails: 1 1/2″ (.070″) w x 1 1/2″ (.100)” h
Pickets: 1″ x 1″ (.065″)
Picket Spacing: 3.75″ between pickets
Racking: Standard Section Racks 17″ in an 8′ Section

Model 2233 – 3-RAIL FLAT TOP W/ALT. SPEAR POINTS

FENCE SPECIFICATIONS
Heights: 48″, 54″, 60″, 72″
Sections: 8′ Centers (Standard); Available in Per Foot Sections from 3′ to 8′
and Per Inch Sections from 36″ to 96″ (even spacing between verticals)
Standard Posts: 2 1/2″ x 2 1/2″ (.090″)
Heavy Duty Posts: 2 1/2″ x 2 1/2″ (.125″)
Gate Posts: 2 1/2″ x 2 1/2″ (.090″) w/ Inserts = .215″ Wall, 4″ x 4″ (.125″), 6″ x 6″ (.185″)
Post Caps: 2 1/2″, 4″, 6 Flat (Standard); 2 1/2″, 4″ Ball (Optional)
Rails: 1 1/2″ (.070″) w x 1 1/2″ (.100)” h
Pickets: 1″ x 1″ (.065″)
Picket Spacing: 3.75″ between pickets
Finial Option: Triad and Quad
Racking: Standard Section Racks 17″ in an 8′ Section

Model 2131 – 3-RAIL W/SPEAR POINTS

FENCE SPECIFICATIONS
Heights: 48″, 54″, 60″, 72″
Sections: 8′ Centers (Standard); Available in Per Foot Sections from 3′ to 8′
and Per Inch Sections from 36″ to 96″ (even spacing between verticals)
Standard Posts: 2 1/2″ x 2 1/2″ (.090″)
Heavy Duty Posts: 2 1/2″ x 2 1/2″ (.125″)
Gate Posts: 2 1/2″ x 2 1/2″ (.090″) w/ Inserts = .215″ Wall, 4″ x 4″ (.125″), 6″ x 6″ (.185″)
Post Caps: 2 1/2″, 4″, 6 Flat (Standard); 2 1/2″, 4″ Ball (Optional)
Rails: 1 1/2″ (.070″) w x 1 1/2″ (.100)” h
Pickets: 1″ x 1″ (.065″)
Picket Spacing: 3.75″ between pickets
Finial Option: Triad and Quad
Racking: Standard Section Racks 17″ in an 8′ Section

Model 2132 – 3-RAIL W/ALT. SPEAR POINTS

FENCE SPECIFICATIONS
Heights: 48″, 54″, 60″, 72″
Sections: 8′ Centers (Standard); Available in Per Foot Sections from 3′ to 8′
and Per Inch Sections from 36″ to 96″ (even spacing between verticals)
Standard Posts: 2 1/2″ x 2 1/2″ (.090″)
Heavy Duty Posts: 2 1/2″ x 2 1/2″ (.125″)
Gate Posts: 2 1/2″ x 2 1/2″ (.090″) w/ Inserts = .215″ Wall, 4″ x 4″ (.125″), 6″ x 6″ (.185″)
Post Caps: 2 1/2″, 4″, 6 Flat (Standard); 2 1/2″, 4″ Ball (Optional)
Rails: 1 1/2″ (.070″) w x 1 1/2″ (.100)” h
Pickets: 1″ x 1″ (.065″)
Picket Spacing: 3.75″ between pickets
Finial Option: Triad and Quad
Racking: Standard Section Racks 17″ in an 8′ Section

Model 2240 – 4-RAIL FLAT TOP

FENCE SPECIFICATIONS
Heights: 84″, 96″
Sections: 8′ Centers (Standard); Available in Per Foot Sections from 3′ to 8′
and Per Inch Sections from 36″ to 96″ (even spacing between verticals)
Standard Posts: 2 1/2″ x 2 1/2″ (.125″)
Gate Posts: 4″ x 4″ (.125″), 6″ x 6″ (.185″)
Post Caps: 2 1/2″, 4″, 6 Flat (Standard); 2 1/2″, 4″ Ball (Optional)
Rails: 1 1/2″ (.070″) w x 1 1/2″ (.100)” h
Pickets: 1″ x 1″ (.065″)
Picket Spacing: 3.75″ between pickets
Racking: Standard Section Racks 17″ in an 8′ Section

Model 2243 – 4-RAIL FLAT TOP W/ALT. SPEAR POINTS

FENCE SPECIFICATIONS
Heights: 84″, 96″
Sections: 8′ Centers (Standard); Available in Per Foot Sections from 3′ to 8′
and Per Inch Sections from 36″ to 96″ (even spacing between verticals)
Standard Posts: 2 1/2″ x 2 1/2″ (.125″)
Gate Posts: 4″ x 4″ (.125″), 6″ x 6″ (.185″)
Post Caps: 2 1/2″, 4″, 6 Flat (Standard); 2 1/2″, 4″ Ball (Optional)
Rails: 1 1/2″ (.070″) w x 1 1/2″ (.100)” h
Pickets: 1″ x 1″ (.065″)
Picket Spacing: 3.75″ between pickets
Finial Option: Triad and Quad
Racking: Standard Section Racks 17″ in an 8′ Section

Model 2141 – 4-RAIL W/SPEAR POINTS

FENCE SPECIFICATIONS
Heights: 84″, 96″
Sections: 8′ Centers (Standard); Available in Per Foot Sections from 3′ to 8′
and Per Inch Sections from 36″ to 96″ (even spacing between verticals)
Standard Posts: 2 1/2″ x 2 1/2″ (.125″)
Gate Posts: 4″ x 4″ (.125″), 6″ x 6″ (.185″)
Post Caps: 2 1/2″, 4″, 6 Flat (Standard); 2 1/2″, 4″ Ball (Optional)
Rails: 1 1/2″ (.070″) w x 1 1/2″ (.100)” h
Pickets: 1″ x 1″ (.065″)
Picket Spacing: 3.75″ between pickets
Finial Option: Triad and Quad
Racking: Standard Section Racks 17″ in an 8′ Section

Model 2142 – 4-RAIL W/ALT. SPEAR POINTS

FENCE SPECIFICATIONS
Heights: 84″, 96″
: 8′ Centers (Standard); Available in Per Foot Sections from 3′ to 8′
and Per Inch Sections from 36″ to 96″ (even spacing between verticals)
Standard Posts: 2 1/2″ x 2 1/2″ (.125″)
Gate Posts: 4″ x 4″ (.125″), 6″ x 6″ (.185″)
Post Caps: 2 1/2″, 4″, 6 Flat (Standard); 2 1/2″, 4″ Ball (Optional)
Rails: 1 1/2″ (.070″) w x 1 1/2″ (.100)” h
Pickets: 1″ x 1″ (.065″)
Picket Spacing: 3.75″ between pickets
Finial Option: Triad and Quad
Racking: Standard Section Racks 17″ in an 8′ Section

The Industrial Aluminum Fence (5000 Series) was designed as ornamental fencing for industrial businesses, entryways, business parts, cemeteries, and swimming pools (be sure to check local pool codes). With 1½” x 1½” rails, 1″ spindles, and gates are welded, this series gives options for those customers that need a heavy-duty fence to define their property.

Model 5131 – 3-RAIL W/SPEAR POINTS

FENCE SPECIFICATIONS
Heights: 48″, 54″, 60″, 72″
Section Length: 8′ Centers
Standard Posts: 2 1/2″ x 2 1/2″ (.090″)
Heavy Duty Posts: 2 1/2″ x 2 1/2″ (.125″)
Gate Posts: 2 1/2″ x 2 1/2″ (.125″), 4″ x 4″ (.125″), and 6″ x 6″ (.185″)
Post Caps: 2 1/2″, 4″ or 6″ Flat (standard); 2 1/2″ or 4″ Ball (optional)
Rails: 1 1/2″ (.070″) w x 1 1/2″ (.095″) h
Pickets: 1″ x 1″ (.062″)
Picket Spacing: 3.750″ Between Pickets
Finial Options: Quad and Triad
Section Options: Short Picket Option
Racking: Standard Section Racks 12″ in an 8′ Section

Model 5132 – 3-RAIL W/ALT. SPEAR POINTS

Model 5141 – 4-RAIL W/SPEAR POINTS

FENCE SPECIFICATIONS
Heights: 84″, 96″
Section Length: 8′ Centers
Standard Posts: 2 1/2″ x 2 1/2″ (.125″)
Gate Posts: 2 1/2″ x 2 1/2″ (.125″), 4″ x 4″ (.125″), and 6″ x 6″ (.185″)
Post Caps: 2 1/2″, 4″ or 6″ Flat (standard); 2 1/2″ or 4″ Ball (optional)
Rails: 1 1/2″ (.070″) w x 1 1/2″ (.095″) h
Pickets: 1″ x 1″ (.062″)
Picket Spacing: 3.750″ Between Pickets
Finial Options: Quad and Triad
Section Options: Short Picket Option
Racking: Standard Section Racks 12″ in an 8′ Section

Model 5142 – 4-RAIL W/ALT. SPEAR POINTS

Model 5220 – 2-RAIL FLAT TOP

FENCE SPECIFICATIONS
Height: 54″*
Section Length: 8′ Centers
Standard Posts: 2 1/2″ x 2 1/2″ (.090″)
Heavy Duty Posts: 2 1/2″ x 2 1/2″ (.125″)
Gate Posts: 2 1/2″ x 2 1/2″ (.125″), 4″ x 4″ (.125″), and 6″ x 6″ (.185″)
Post Caps: 2 1/2″, 4″ or 6″ Flat (standard); 2 1/2″ or 4″ Ball (optional)
Rails: 1 1/2″ (.070″) w x 1 1/2″ (.095″) h
Pickets: 1″ x 1″ (.062″)
Picket Spacing: 3.750″ Between Pickets
Racking: Standard Section Racks 12″ in an 8′ Section

Model 5230 – 3-RAIL FLAT TOP

FENCE SPECIFICATIONS
Heights: 48″, 55″*, 60″, 72″
Section Length: 8′ Centers
Standard Posts: 2 1/2″ x 2 1/2″ (.090″)
Heavy Duty Posts: 2 1/2″ x 2 1/2″ (.125″)
Gate Posts: 2 1/2″ x 2 1/2″ (.125″), 4″ x 4″ (.125″), and 6″ x 6″ (.185″)
Post Caps: 2 1/2″, 4″ or 6″ Flat (standard); 2 1/2″ or 4″ Ball (optional)
Rails: 1 1/2″ (.070″) w x 1 1/2″ (.095″) h
Pickets: 1″ x 1″ (.062″)
Picket Spacing: 3.750″ Between Pickets
Section Options: Short Picket Option
Racking: Standard Section Racks 12″ in an 8′ Section

Model 5233 – 3-RAIL FLAT TOP W/ALT. SPEAR POINTS

FENCE SPECIFICATIONS
Heights: 48″, 55″*, 60″, 72″
Section Length: 8′ Centers
Standard Posts: 2 1/2″ x 2 1/2″ (.090″)
Heavy Duty Posts: 2 1/2″ x 2 1/2″ (.125″)
Gate Posts: 2 1/2″ x 2 1/2″ (.125″), 4″ x 4″ (.125″), and 6″ x 6″ (.185″)
Post Caps: 2 1/2″, 4″ or 6″ Flat (standard); 2 1/2″ or 4″ Ball (optional)
Rails: 1 1/2″ (.070″) w x 1 1/2″ (.095″) h
Pickets: 1″ x 1″ (.062″)
Picket Spacing: 3.750″ Between Pickets
Finial Option: Quad and Triad
Section Options: Short Picket Option
Racking: Standard Section Racks 12″ in an 8′ Section

Model 5240 – 4-RAIL FLAT TOP

FENCE SPECIFICATIONS
Heights: 84″, 96″
Section Length: 8′ Centers
Standard Posts: 2 1/2″ x 2 1/2″ (.125″)
Gate Posts: 2 1/2″ x 2 1/2″ (.125″), 4″ x 4″ (.125″), and 6″ x 6″ (.185″)
Post Caps: 2 1/2″, 4″ or 6″ Flat (standard); 2 1/2″ or 4″ Ball (optional)
Rails: 1 1/2″ (.070″) w x 1 1/2″ (.095″) h
Pickets: 1″ x 1″ (.062″)
Picket Spacing: 3.750″ Between Pickets
Section Options: Short Picket Option
Racking: Standard Section Racks 12″ in an 8′ Section
